Key Features
| Mono channel digital power amplifier |
| D-class Amplifier |
| Compact chassis |
| Built-in low pass filter |
| Speaker Level Input |
| Signal sensing Turn-on |
| Extruded aluminum heat sink design |
| 2 ohms load capability |
| Screw-type terminals |
Amplifier Features
| Class D Amplifier | Yes |
| Full Range Digital Amplifier | Yes |
| Load Capability | 2Ω Stable |
| Rated power output (4Ω) | 300W x 1 (4Ω) |
| Rated power output | 500W x 1 (2Ω) |
| CEA-2006 Compliant | Yes |
| Low-pass Filter | Yes |
| Switched Mode Power supply | Yes, with Power MOS-FET |
| Single Side Terminals | Yes |
| Chassis | Extruded aluminum het sink design |
Amplifier-Specifications
| Rated power output (4Ω, 14,4V) | 300W x 1 (20Hz ~ 200Hz, 1%THD) |
| Rated power output (2Ω, 14,4V) | 500W x 1 (100Hz, 1%THD) |
| Rated power output (CEA-2006) | 300Watts RMS x 1 at 4 ohms and 1% THD |
| Low-pass Filter | 50~200Hz (-24dB/oct) |
| Bass Boost Circuit | 40Hz, 18dB (B-Channel) |
| RCA Input Sensitivity | 0.2 ~ 5V |
| Input Impedance | 10kΩ |
| Signal to Noise Ratio | 100dB |
| Signal to noise ratio (CEA-2006) | 85dBa (Reference: 1 Watt into 4 Ohms) |
| Frequency response (+0dB, -1dB) | 20Hz ~ 200Hz |
| Operating voltage | 14.4V (11V ～ 16V allowable) |
| Maximum current consumption | 34A |
| Dimensions (WxHxD) | 170 x 55 x 187(mm), |
| Installation Size (WxHxD) | 170 x 55 x 187 (mm) |
| Weight | 1.3kg |
-
Maximum Output Power:500 W
-
RMS Power per channel at 2 ohm:500 W
-
RMS Power per channel at 4 ohm:300
-
Built-in filters:Low-pass filter (LPF)
-
Minimum Impedance:2 Ohm Ohm
-
Amplifier Class:Class D
