Key Features
| STAGE SOUND SERIES |
| Flush Mount Speaker |
| 2-Way 2-Speaker System |
| 17 cm Polypropylene Woofer Cone |
| Heavy-Duty Woofer Magnet Circuit |
| 25mm Blanced Dome Tweeter |
| Tweeter Sound Field Enhancer & Electro-Dynamic Driver |
| 300W Peak Power |
| 30W RMS Power |
| Speaker grill included |
Speaker/woofer Specifications
| Peak Input Power | 300W |
| Rated Input Power | 30W |
| Woofer Cone material | Polypropylene (PP) Cone |
| Speaker Basket | Steel |
| Speaker Surround | Cloth |
| Sensitivity | 89dB/W/m |
| Frequency Response | 35Hz ~ 22000Hz |
| Speaker Impedance | 4Ω |
| Dimensions with Grill (WxHxD) | 176 x 176 x 70mm |
| Dimensions w/o Grill (WxHxD) | 165 x 165 x 44.2mm |
| Mounting Depth | 44.2mm |
| Mouting Hole Diameter Ø | 142mm |
| Tweeter Height | 7mm |
| Speaker Weight with Grille (pc.) | 602gr |
| Speaker Weight w/o Grille (pc.) | 536gr |
| Gross Weight | 1305gr |
| Weight of Magnet | 220gr |
Tweeter Specifications
| Cone Size | 25mm |
| Cone Material | Balanced Dome |
Accessories
| Screws (Parker-type) | Ø 4 x 25mm, 8 pieces |
| Speed nut | φ 4, 8 pieces |
| Speaker grille included | Yes |
| Speaker cable | 0.3m |
-
Design:2-way
-
Max. Power:300 W
-
RMS Power:30 W
-
Sensitivity:89 dB/W/m
-
Mounting Depth:44.2 mm
